Security Management Appliances
Check Point Smart-1 7th Generation appliances deliver standard-setting security management on R82: intuitive zero trust policy and compliance, a broad integration ecosystem, and accelerated administration through automation and AI. Dynamic policy enforcement secures DevOps assets and cloud workloads, while AI-powered services — preventive monitoring and alerting, actionable policy insights, and generative AI assistance — solve issues faster, combined with an open garden of integrations for automating cross-product workflows.
Key Features and Benefits
- Unified security management platform: manage everything from policy to threat prevention with a single console across physical and virtual environments
- Greater on-demand scalability: up to 1,500 gateways in a single domain or SMS, and up to 10,000 gateways per appliance in Multi-Domain configuration, with up to 200 domains
- Accelerated log rate: up to 75,000 sustained indexed logs per second and 2,757 GB per day of logs for real-time event analysis, compliance checks and reporting
- Powerful AI tools: AI Copilot generative assistant, Policy Insights, Policy Auditor, SmartEvent, Compliance and Infinity Playblocks — plus AI-powered preventive firewall infrastructure monitoring (AIOps)
- Efficient Multi-Domain: manage hundreds of private networks within a single infrastructure, with up to 200 domains per appliance
- Reports & Compliance: over 300 security best practices and regulatory compliance checks with scheduled, one-click reporting
Capacity & Performance
| Specification | 700S | 700M | 7000L | 7000XL | 7000UL |
|---|---|---|---|---|---|
| Managed Gateways (Base/Plus) | 5/10 | 25/50 | 75/150 | 200/400 | 250/500 |
| Max Gateways per Domain/SMS | 10 | 50 | 150 | 1,500 (gateway expansion req.) | |
| Maximum Domains (Multi-Domain) | — | — | 50 | 200 | — |
| Sustained Indexed Logs / Sec | 10,000/10,000 | 22,000/20,000 | 32,000/32,000 | 60,000/60,000 | 75,000/75,000 |
| GB per Day of Logs | 430 | 800 | 1,218 | 2,284 | 2,757 |
| Max Gateways at Appliance Level | N/A | 10,000 (Multi-Domain license & expansion req.) | |||
Hardware Specifications
| Specification | 700S | 700M | 7000L | 7000XL | 7000UL |
|---|---|---|---|---|---|
| Cores/Threads | 4/8 | 14/20 | 24/48 | 48/96 | 56/112 |
| Memory (RAM) Default/Max | 16/32 GB | 32/64 GB | 128/192 GB | 256/384 GB | |
| Storage Options | 2×4TB HDD | 2×8TB HDD | 4×8TB or 8×8TB HDD | 6×4TB or 12×4TB NVMe SSD | 6×8TB or 12×8TB NVMe SSD |
| Effective Storage (default) | 4TB | 8TB | 14.5TB | 17.4TB | 34.9TB |
| Effective Storage (max) | — | — | 43.6TB | 34.9TB | 69.8TB |
| Enclosure / Dimensions (W×D×H) | 1U, 438×446.8×44.2mm | 2U, 438×607.55×88.6mm | |||
| Weight | 8.03 kg | 8.78 kg | 18.88 kg | 15.697 kg | |
| Power Supply | 1+1 internal redundant 260W | 2×300W hot-swappable | 2×1300W hot-swappable | 2×1600W hot-swappable (DC optional) | |
| Power Consumption (avg/max) | 126W/210W | 114W/190W | 436W/728W | 523W/872W | 540W/919W |
All models include 4×1/10GbE SFP ports + 1×copper 1GbE, a Lights Out Management (LOM) card and RAID support. Smart-1 700/7000 appliances require software version R82 or higher.
Ordering Information (selected)
| SKU | Description |
|---|---|
| CPAP-NGSM700S-BASE / -PLUS | Smart-1 700S Base/Plus Security Management, Log and SmartEvent appliance (5/10 gateways) |
| CPAP-NGSM700M-BASE / -PLUS | Smart-1 700M Base/Plus appliance (25/50 gateways) |
| CPAP-NGSM7000L-BASE / -PLUS | Smart-1 7000L Base/Plus appliance (75/150 gateways) |
| CPAP-NGSM7000XL-BASE / -PLUS | Smart-1 7000XL Base/Plus appliance (200/400 gateways) |
| CPAP-NGSM7000UL-BASE / -PLUS | Smart-1 7000UL Base/Plus appliance (250/500 gateways) |
| CPAP-NGSM7000xx-MLOG-10 series | Multi-Log appliances for 10 domains (Base/Plus) |
| CPAC-NGSMxxx-UPG-PLUS series | Base-to-Plus upgrade kits (incl. SmartEvent variants) |
Source: Check Point Quantum Smart-1 7th Generation Datasheet (May 28, 2025). Contact us for the full SKU, upgrade and expansion list.
