3950 Appliance
Check Point Force 3950 Branch Office Network Firewall, optimized for SD-WAN and designed for branch offices. Delivers up to 20 Gbps firewall, 16.2 Gbps next generation firewall and 5.5 Gbps threat prevention throughput with integrated AI/ML security and power efficiency.
Key Benefits
- Complete AI Security: discover and secure all the AI apps, LLMs, agents and MCP servers in your network
- Top Security Effectiveness: Check Point ranks #1 in third-party malware, phishing and vulnerability exploit blocking benchmarks (Miercom, NSS)
- Unified Management & Ops Efficiency: increase protection and reduce TCO with a consolidated security architecture
- Network Resilience & Power Efficiency: load-balanced firewall clustering, on-demand expansion, resilient access to mission-critical applications with lower power consumption
Performance
| Metric | Value |
|---|---|
| Firewall throughput (enterprise test conditions) | 20 Gbps |
| Next Generation Firewall | 16.2 Gbps |
| Threat Prevention | 5.5 Gbps |
| VPN (AES-GCM 1452B) | 17.5 Gbps |
| Connections per second | 130,000 |
Platform Highlights
- Comprehensive security: NGFW, site-to-site & remote access VPN, application & URL filtering, IPS, antivirus & anti-bot, advanced DNS security, sandboxing with file sanitization, agentless zero-phishing
- Processor: 8 物理核; Memory: 32GB; Storage: 480GB SSD NVMe M.2
- Integrated SD-WAN optimization; high availability: Active/Active L2, Active/Passive L2/L3, ClusterXL, VRRP
- Unified management of on-premises and cloud firewalls via SmartConsole / Smart-1
Physical Specifications
| Item | Specification |
|---|---|
| Enclosure | 桌面式（可选机架） |
| Dimensions (WxDxH) | 210 × 209.9 × 42.5 mm |
| Weight | 0.99 kg |
| Power (avg/max) | 46W / 54W |
| Operating | 0°C to 40°C, humidity 5% to 95% |
| Certifications | CB IEC 62368-1, CE, UL, FCC, ROHS, REACH, WEEE, ISO14001 |
Ordering Information
| SKU | Description |
|---|---|
| CPAP-SG3950-SNBT | Base configuration (SandBlast subscription, 1 year) |
Source: Check Point Force 3950 Datasheet (July 2026).
